Product Details
- Place of Origin: Shandong, China (Mainland)
- Brand Name: JULONG
- Model Number: HZ-200GT
| Specifications | |
|---|---|
| Unity machine parameter | |
| Drilling depth | 30--200m |
| End hole caliber | 500-75mm |
| Drill rod caliber | 50mm |
| Drilling angle | 90°～75° |
| Drill weight (No include power) | 910kg |
| Unity machine dimensions | 2.5×1×1.3 2.5×0.9×1.3m |
| Spindle | |
| spindle speed | 64、128、287、557r/min |
| Spindle stroke | 450mm |
| Hoist | |
| Max .single line hoisting capacity | 2400kg |
| Single line lifting speed | 17、35、75、151r/min |
| Tightrope caliber | 12.5mm |
| Tightrope cubic measure | 35m |
| Hug floodgate caliber | 254mm |
| Hug floodgate belt width | 70mm |
| Distance between drill and hole | 400mm |
| Mud pump | |
| Type | Horizontal single urn twin-action |
| Displacement | 170L/min |
| Diesel engine | S1115 Model 22HP |
| Electric motor | Y160M—4 15kw 1440r/min |
| Maximum pressure | 1.5Mpa |
| Work pressure | 0.7Mpa |
| Water inlet caliber | 40mm |
| Water to exit caliber | 30mm |
| Triangle conveyer belt | B1728mm |
- Place of Origin: Shandong, China (Mainland)
- Brand Name: JULONG
- Model Number: HZ-200GT
